Moniteur Broadcast RUIGE TL-P890HD: 8,9¨ Moniteur caméscope 3D-LUT intégré

Description

FEATURE
1. 1920×1200 Native Resolution（IPS Technology）
2. Luminance waveform in SDI mode.
3. Grade & Step false color
4. Peaking Focus
5. Safety marker / Subtitle marker / TALLY / Static UMD
6. Black & white, blue, mono color switch
7. Compatible with SDI1/1.001 fps
8. HDCP 1.1 / HDMI 1.3
9. H/V Delay
10. Audio meter in 16 channels (Simultaneous display 8 channels)
11. 4:3 / 16:9 / Letter Box / Over Scan
12. Safety lock
13. Built-in 3D-LUT (REC709, SMPTE-C, EBU)
14. Fast keys (custom setting)
15. On display battery meter
16. Static-frame

SPECIFICATION
– PANEL
SIZE 8.9”
RESOLUTION 1920×RGB×1200
DOT PITCH 0.09975（H）×0.09975（V）mm
ASPECT RATIO 16:9 / 4:3
BACK LIGHT WLED
BRIGHTNESS（MAX） 500cd/m2
CONTRAST（MAX） 800:1
Color depth 8Bits(16.7M colors)
IMAGE PROCESSING 10Bits
RESPONSE TIME 10ms
VIEWING ANGLE H170° / V170°

– VIDEO IN
3G/HD/SD-SDI 2 x BNC
COMPOSITE(CVBS) 1 x BNC
COMPONENT 1 x 3 BNC
HDMI 1 x HDMI Type-A

– VIDEO OUT
3G/HD/SD-SDI 1 x BNC
COMPOSITE 1 x BNC

– AUDIO
audio demultiplexing Yes
audio meters 16 channels
Speakers Stereo 1×8Ω/1W
headset yes

– Operation requirement
Input voltage DC 12V
Power consumption 15W
Working temperature 0-40℃
Store temperature -20-70℃
Store humidity 0%-90% no condensation

– Structure
Shell material Aluminum profile
Dimension（mm） L222 x H177 x D58.5mm
Weight Around 1.5Kg

Standard Accessories
AC-DC adapter 1
AC power cable 1
HDMI plug lock 1
Stand base 2
D-Tap power cable 1
Convertible Sunhood 1

Fonction

Fonction sketch – Front view

1 Tally (indicator)
2 Speaker
3 Stand base（Detachable）
4 Power switch（Standby）
5 Multiple functions Knob / key
6 Main menu
7 Input signal select key
8 Shortcut keys
9 Silent operation key
10 Status lock / unlock
11 Headphone Jack
■F1、F2、F3、F4 Shortcut（user-defined）

Fonction sketch – back view

12 HDMI Input
13 3G / HD/SD-SDI Output
14 3G / HD/SD-SDI Input
15 Composite I/O
16 Audio input
17 Component (Y/Pr/Pb) input
18 Battery adaptor (optional)
19 Tally signal input
20 Power Switch
21 DC 12V Power Input
22 HDMI adapter (optinal)
